Fourstroke LT ONE

BORDEAUX RED / BLACK

SRAM GX Eagle Drivetrain
Rock Shox SID Select+ Fork / Rock Shox SIDLUXE Select+ Shock
DT Swiss M 1900 Wheelset

Regular price€5.999,00
/
Tax included.

SKU: 30005392
Size

Fourstroke LT ONE

Parts & Accessories

  • Shipped to your local bike shop
Fourstroke LT is an XC bike designed for riders who want even more performance. Offering trail-riding at speed with progressive 120mm of our updated APS dual-link suspension travel, there is no limit to what you and the Fourstroke LT can achieve. The full-carbon frame includes our most progressive BWC geometry now fitting two water bottles, integrated fork stopper and frame protection. Fourstroke LT ONE plays the trails with confidence with a SRAM GX Eagle drivetrain, RockShox SID Select+ fork and RockShox SIDLuxe Select+, DT Swiss M 1900 wheels with 30mm inner width and the Bikeyoke Divine seatpost.

Technology

Technical Overview

Frameset

Frame:
Fourstroke LT Carbon | APS Suspension System | 120mm Travel | Fully Guided Internal Cable Routing | Post Mount Disc | 12 x 148mm Boost Thru-Axle

Fork:
RockShox SID Select+

Suspension

Front Suspension:
RockShox SID Select+

Rear Suspension:
RockShox SIDLUXE Select+

Cockpit

Stem:
Truvativ Atmos 7K

Handlebar:
BMC MRB 03 | 760mm

Seat

Seatpost:
Bikeyoke Divine

Saddle:
Fizik Antares R7

Drivetrain

Crankset:
SRAM Stylo 6k Eagle

Chainrings:
32T

Cassette:
SRAM XG-1275 Eagle

Cassette Size:
10-52T

Chain:
SRAM NX Eagle

Rear Derailleur:
SRAM GX Eagle

Shifters:
SRAM GX Eagle

Gears:
1 x 12

Bottom Bracket:
PF92 Bottom Bracket

Brakes

Brake Levers / Calipers:
SRAM G2 RS

Rotors:
SRAM Centerline | 6-Bolt

Rotor Size (F/R):
180 / 180mm

Wheels

Rims:
DT Swiss M 1900 | 30mm Inner Width

Hubs (F/R):
DT Swiss 370 | Ratchet LN18

Tires:
Maxxis Rekon 2.4" | EXO TR

Tubeless Information:
Tubeless Ready Rims | Tubetype Tires

Additional Information

Tire Clearance:
62mm

ASTM Classification:
Level 3

System Weight Limit:
110kg

SizeSMLXL
SCOR Size
Rider Height<172172-182180-188>188
Reach437457477500
Stack584592600615
Bar Drop
Bar Reach
Bar Rise15151515
Bar Sweep9999
Bar Width760760760760
Base Bar Drop Flat Cockpit
Base Bar Drop V-Cockpit
Base Bar Reach Flat Cockpit
Base Bar Reach V-Cockpit
BB Drop38383838
BB Drop (SLACK)
BB Drop (STEEP)
BB Height (SLACK)
BB Height (STEEP)
Chainstay
Crank Length165170175175
LT | BB Drop (SLACK)
LT | BB Drop (STEEP)
LT | BB Height (SLACK)
LT | BB Height (STEEP)
LT | Chainstay
LT | Fork Length
LT | Fork Rake
LT | Frame Size
LT | Front Center (SLACK)
LT | Front Center (STEEP)
LT | Head Tube
LT | HT Angle (SLACK)
LT | HT Angle (STEEP)
LT | Reach (SLACK)
LT | Reach (STEEP)
LT | Rider Height
LT | Seat Tube
LT | ST Angle @750mm Saddle Height (SLACK)
LT | ST Angle @750mm Saddle Height (STEEP)
LT | ST Angle Actual (SLACK)
LT | ST Angle Actual (STEEP)
LT | ST Angle Effective (SLACK)
LT | ST Angle Effective (STEEP)
LT | Stack (SLACK)
LT | Stack (STEEP)
LT | Stand Over Height (80 in Front of BB)
LT | Stand Over Height (Lowest Point)
LT | Top Tube (SLACK)
LT | Top Tube (STEEP)
LT | Wheelbase (SLACK)
LT | Wheelbase (STEEP)
ST | BB Drop (SLACK)
ST | BB Drop (STEEP)
ST | BB Height (STACK)
ST | BB Height (STEEP)
ST | Chainstay
ST | Fork Length
ST | Fork Rake
ST | Frame Size
ST | Front Center (SLACK)
ST | Front Center (STEEP)
ST | Head Tube
ST | HT Angle (SLACK)
ST | HT Angle (STEEP)
ST | Reach (SLACK)
ST | Reach (STEEP)
ST | Rider Height
ST | Seat Tube
ST | ST Angle @750mm Saddle Height (SLACK)
ST | ST Angle @750mm Saddle Height (STEEP)
ST | ST Angle Actual (SLACK)
ST | ST Angle Actual (STEEP)
ST | ST Angle Effective (SLACK)
ST | ST Angle Effective (STEEP)
ST | Stack (SLACK)
ST | Stack (STEEP)
ST | Stand Over Height (80 in Front of BB)
ST | Stand Over Height (Lowest Point)
ST | Top Tube (SLACK)
ST | Top Tube (STEEP)
ST | Wheelbase (SLACK)
ST | Wheelbase (STEEP)
Fork Length530530530530
Fork Rake44444444
Front Center711743760790
Front Center (SLACK)
Front Center (STEEP)
Head Tube8493.5101118
Head Tube Angle66.566.566.566.5
HT Angle (SLACK)
HT Angle (STEEP)
Pad Reach Flat Cockpit
Pad Reach V-Cockpit
Pad Stack Flat Cockpit
Pad Stack V-Cockpit
Reach (SLACK)
Reach (STEEP)
Rear Center431430.5431431
Saddle Height Range
Seat Angle76.776.776.776.7
Seat Tube420430460490
Seatpost Drop150160160185
Seatpost Length
Seatpost Offset
ST Angle @750mm Saddle Height (SLACK)
ST Angle @750mm Saddle Height (STEEP)
ST Angle Actual (SLACK)
ST Angle Actual (STEEP)
ST Angle Effective (SLACK)
ST Angle Effective (STEEP)
Stack (SLACK)
Stack (STEEP)
Stand Over Height (80 in Front of BB)
Stand Over Height (Lowest Point)
Standover Height727727727767
Stem Angle6666
Stem Length40505060
Top Tube576599623651
Top Tube (SLACK)
Top Tube (STEEP)
Trail1151151151115
Wheelbase1140117211891219
Wheelbase (SLACK)
Wheelbase (STEEP)
